BIQU B1 IdeaMaker Profiles – PLA / PETG

I previously reviewed the BIQU B1 (BIQU B1 Review: Ender 3 V2 Killer?) and during the process I also tuned the BIQU B1 IdeaMaker profile for it.
In this article, I will share my IdeaMaker profile for BIQU B1 made for PLA and PETG. These profiles are tuned to deliver a good balance between speed and print quality, and worked really well for me.

IdeaMaker profile for BIQU B1

The PLA profile can be used out of the box with this material. Nozzle temperature is set to 205C and bed temperature is set to 50C. Please note that I included two different profiles. One is for the stock extruder and the second one is made for the BMG extruder.

For the PETG profile, nozzle temperature is set to 235C, bed temperature is set to 70C.
Fan speed is set to 0 for the first layer, 10% for the second layer and 30% starting from the 3rd layer. This is done in order to minimize issues with adhesion.

You can download the IdeaMaker profile for BIQU B1 from the links below:

BIQU B1 IdeaMaker Profile – PLA – Stock – 3DPrintBeginner
BIQU B1 IdeaMaker Profile – PLA – BMG – 3DPrintBeginner
BIQU B1 IdeaMaker Profile – PETG – Stock- 3DPrintBeginner
BIQU B1 IdeaMaker Profile – PETG – BMG – 3DPrintBeginner

How to install the BIQU B1 IdeaMaker profile

In order to install the IdeaMaker profile for BIQU B1, please follow the steps below:

  1. Download and install the IdeaMaker slicer from Raise3D website, then select the appropriate version according to your operating system.
    Download IdeaMaker slicer
  2. Open IdeaMaker and cancel the Configuration Wizzard
    Cancel the Configuration Wizzard
  3. Click on the “Play” button on the left side, then click on More and finally Import.
    Import IdeaMaker Profile
  4. Select the BIQU B1 profile – 3DPrintBeginner.bin file previously downloaded.
    BIQU B1 IdeaMaker profile
  5. In the Import Slicing Template screen, make sure you check the buttons like in the screenshot below then click OK.
    Import Printer Profile BIQU B1
  6. If you followed the steps, now your IdeaMaker profile for Sapphire Plus should be loaded and you can slice your first model.
    BIQU B1 IdeaMaker profile imported

Print Quality with the BIQU B1 and IdeaMaker profile

Below, I attached a few test prints done with the IdeaMaker profile for BIQU B1.

Scruffy

Scruffy from Futurama was the first test I did with the final version of the profile. Except for some minor issues, the print looks great.

  • Material: Sunlu Silk Red Copper PLA
  • Layer Height: 0.15mm
  • Nozzle Temperature: 200C
  • Bed Temperature: 60C
  • Print Speed: 50 mm/s

Mandrill

The Mandrill by Sid Naique’s Patreon was printed with the same BIQU B1 IdeaMaker profile with good results.

  • Material: Sunlu Silk Red Copper PLA
  • Layer Height: 0.15mm
  • Nozzle Temperature: 200C
  • Bed Temperature: 60C
  • Print Speed: 50 mm/s

Wrapping Up

I put a lot of work in this, so I hope these IdeaMaker profiles will work well for you. Let me know if you have any questions in the comments below.
