Ultimate 3D Printer Nozzle Comparison
I always wanted to do a 3D printer nozzle comparison to see what are the differences between nozzles and if it’s worth buying more expensive nozzles. Well, this finally happened and in the following article you will find a visual comparison between a large selection of nozzles.
Testing Apparatus
Because I want be able to test future hardware better, I purchased an Andonstar ADSM201 electronic microscope. It’s not the best electronical microscope on the marked but it does it’s job well enough to say it’s worth the money.
I regret not spending just a bit more to get the Andonstar ADSM301 which can also be used for measuring with the included software. But hey! Live and learn.
To be honest, the price difference was a bit higher at the time but anyway. I’m still happy with it.
If you know any microscope software which can be used on a PC for measuring please let me know in the comments.
I printed a white PLA shield to be able to diffuse the light better. It’s really hard to get close to a shiny object so this helped a bunch. Each nozzle has been photographed from three sides so you can see the quality differences between them.
What’s the best 3D Printer Nozzle Upgrade?
In my experience with a boatload of different nozzles, I found out that most of the cheap nozzles, or the ones included with some printers are bad. Like, really bad. This is the reason why I always recommend people to buy a good nozzle.
You don’t need to spend a huge amount of money to get better quality. Just pick up some nozzles machined well because this can make your prints look a lot better.
People often spend money on all kind of upgrades but they cheap out when it comes to nozzles. This is a bad idea because a nozzle is important to print quality.
For example, if the nozzle hole is not cut to a precise size your printed lines can be different. This can be somewhat compensated by performing a flow calibration but it’s an extra step you need to do.
It’s also important to use different nozzles for different materials and printing situations. It’s not a good idea to print abrasive filament (ex: carbon fiber filament) with a brass nozzle because the tip will get sanded and the extrusion hole will get larger over time. This can happen even during a long print.
If you’re thinking: “No problem, I will just get a hardened steel nozzle“. Well, it’s also not the best “all-round” nozzle. The hardened nozzle will be more resistant to wear but it will have lower thermal transfer and you will need to up your temperatures with around 10C to have the correct temperature inside the nozzle.
That’s why you should pick the correct nozzle for the job, and have a few spares just in case.
Performance Comparison for 3D Printer Nozzles
I got this nice table from Trianglelab where they show the thermal conductivity, hardness, maximum printing temperature and the thermal expansion coefficient for various nozzles.
There’s also a nice applicable materials tab which will hep you understand what kind of nozzles are used for different types of materials.
This information should apply to all nozzles which use the same materials in the table.
Trianglelab
Top Quality Brass V6 Nozzle
This is one of the best budget nozzle you can buy. For around 2$ for a nozzle, it’s great. You can see that the machining is great for both the nozzle body and hole.
It’s recommended for PLA if you do a lot of detailed prints because it has a sharp tip which should help with small prints like a miniature.
The Top Quality Brass V6 Nozzle can be purchased from the following websites:
AliExpress
Top Quality Brass Volcano Nozzle
This nozzle is the same as the regular V6 nozzle but made for a Volcano heatblock. The machining is just as good and you can’t really go wrong with it. Because it’s cheap you can easily discard it if it gets messy. There’s also a low cost for regularly replacing the nozzle to make sure the nozzle hole is constant.
The Top Quality Brass Volcano Nozzle can be purchased from the following websites:
AliExpress
T-V6 Brass Nozzle
The T-V6 brass nozzle is similar to the sharp version but it has more it has a different design with more copper on the tip. This should help maintain a constant temperature of the filament right to the point where it leaves the tip. I would use this kind of nozzle if I mainly print PETG or ABS. Same quality machining we love is present with the T-V6
The T-V6 Brass Nozzle can be purchased from the following websites:
AliExpress
T-Volcano Brass Nozzle
The Volcano variant identical to the V6 version but with a longer thread for Volcano heatblocks. Unfortunately, mine had a small ding on the external part of the tip but the hole is intact. I don’t think there’s going to be any kind of issue with that considering it’s so small.
The T-Volcano Brass Nozzle can be purchased from the following websites:
AliExpress
MK8 Brass Nozzle
This MK8 brass nozzle is excellent if you want to upgrade your nozzle on a Creality machine. Excellent finish and a fair price for a well machined nozzle. It’s a bit sharper than the T-V6 but this is just for maintaining the same length as a regular MK8 nozzle. It’s a great all-round nozzle for PLA, PETG, TPU and ABS.
The MK8 Brass Nozzle can be purchased from the following websites:
AliExpress
T-V6 Plated Copper Nozzle
With the T-V6 plated copper nozzle, you will get better thermal performance which comes with copper. The filament will melt more efficiently and it’s a great choice for printing higher temperature materials.
I wouldn’t buy this if I mainly print PLA but for PETG it’s great. I have been using a plated copper nozzle and it performs well. Besides that, the plating should help with PETG because it sticks less on the nozzle tip and it’s easier to clean.
Because of the plating and the nature of the copper, the tip is not perfect like with the brass nozzles but nothing major.
The T-V6 Plated Copper Nozzle can be purchased from the following websites:
AliExpress
T-Volcano Plated Copper Nozzle
The Volcano variant of the T-V6 looks just as good and it’s made for printing faster with a high flow rate. With a copper nozzle you should be able to increase the maximum flow rate of your hotend a bit but for exact values it’s important to do a test.
The tip looks a bit better compared to the T-V6 and this should be an indication that plating is not the same for each nozzle. Maybe Trianglelab’s plating process could be improved.
Otherwise, it’s a great nozzle which will make PETG printing easier.
The T-Volcano Plated Copper Nozzle can be purchased from the following websites:
AliExpress
T-V6 Plated Copper Ruby Nozzle
As you can see, the copper ruby nozzle I pictured below is not new. I’ve used it for a while (around 200 hours of printing) and now it looks like this. But I thought I should share it anyway.
As you can read in my Ultimate 3D Printer Upgrade Purchase Guide I don’t recommend buying ruby nozzles because they are expensive and really delicate. Even tough the hole is intact, the side of the tip has a small chip on it. I haven’t seen a decrease in quality because of that but still it’s such a shame. I’ve learned my lesson and I will avoid ruby nozzles.
There’s also some damage caused by my pliers used when replacing the nozzle. Because copper is softer, you can easily scuff and damage your nozzle so always use a tubular bit with a torque wrench for any copper nozzle to avoid this.
With the same amount of money you can get a dozen regular nozzles and have more print time from them.
The T-V6 Plated Copper Ruby Nozzle can be purchased from the following websites:
AliExpress
Mellow
NF-V6 Sharp Brass Nozzle
I used a half dozen NF-V6 brazz nozzles and on different printers and they worked great. The machining is consistent on all the nozzles I had. These were the nozzles I used for printing a lot of Covid masks and they worked great.
They turn a bit darker after using them for a while but the quality remains the same and I haven’t encountered any issues. I usually change them when they get nasty, but I can’t say I do it for any other reason. For ~2$ they’re the best cheap nozzles you can get.
The NF-V6 Sharp Brass Nozzle can be purchased from the following websites:
AliExpress
NF-V6 Sharp Volcano Brass Nozzle
This is the Volcano sharp nozzle from Mellow and they’re just as good. I have them installed on my Artillery printers to replace the horrible stock nozzles. If you have an Artillery nozzle, this is a good replacement to get if you need a cheap alternative.
These sharp V6 volcano nozzles are also recommended when printing miniatures because of the thin tip.
The NF-V6 Sharp Volcano Brass Nozzle can be purchased from the following websites:
AliExpress
Top Quality Brass V6 Nozzle
The top quality brass V6 nozzles are similar to the Trianglelab version I covered before. Same design and quality. I wouldn’t be surprised if they are the same nozzles but sold under different stores, so choose the one which fits best for you when ordering.
With my nozzle there’s a really minor scuff on the tip which won’t impact the printing quality.
The Top Quality Brass V6 Nozzle can be purchased from the following websites:
AliExpress
Top Quality NF-V6 Volcano Nozzle
Same V6 brass nozzle but in a Volcano formfactor. Nothing new to say about it other than it’s machined really well and can be used as a good all-round nozzle for your Volcano hotend.
The Top Quality NF-V6 Volcano Nozzle can be purchased from the following websites:
AliExpress
NF-V6 Plated Copper Nozzle
The V6 plated copper from Mellow looks just like the Trianglelab version but the tip has a better plated finish. An excellent nozzle if you need to print higher temperature materials and have better prints with PETG.
The NF-V6 Plated Copper Nozzle can be purchased from the following websites:
AliExpress
NF-V6 Volcano Plated Copper Nozzle
The Volcano variant is about the same. Nothing new to add here. Just be careful not to tighten your copper nozzle too much to avoid any kind of damage. Otherwise, smooth printing for a fair price.
The NF-V6 Volcano Plated Copper Nozzle can be purchased from the following websites:
AliExpress
NF-MK8 Plated Copper Nozzle
This MK8 nozzle was bundled with my NF-Smart Copper Hotend and as you can see it’s not great. It has a small chip on the inside of the nozzle. This is not the best thing for a nozzle but during printing I could not see any scuffs on the layer. So maybe it’s fine ?
Besides that, the plating seems to have some kind of damage or oxidation. Not sure why this happened but it is what it is.
The NF-MK8 Plated Copper Nozzle can be purchased from the following websites:
AliExpress
NF-V6 Sharp A2 Hardened Steel Nozzle
I must say, I’m not a big fan of hardened steel nozzles. Firstly, because I don’t have a specific need for them (I mainly print PLA and PETG) but I had a lot of questions about them so they’re added to this comparison.
I like the machining quality and the black color but do keep in mind that Mellow Sharp A2 hardened steel nozzles don’t have a plastic repellent coating so you might get a bit more “stickiness”.
It’s also important to keep in mind that when installing one of these nozzles you should do a temperature tower calibration to see how well the nozzle can transfer the heat from your heatblock. I needed to increase the temperature with ~10C compared to a regular brass nozzle.
Please don’t buy a hardened steel nozzle if you might print some abrasive filament in the future. It’s not worth the cost and the trouble. This is a nozzle specifically made for people who print abrasive filaments more often than regular plastic.
The NF-V6 Sharp A2 Hardened Steel Nozzle can be purchased from the following websites:
AliExpress
NF-V6 Sharp A2 Volcano Hardened Steel Nozzle
As you have probably guessed, the Volcano variant of the Sharp A2 is made for faster printing where you need a longer heating zone to efficiently print at high speeds. Otherwise, it’s the same nozzle as the V6 variant.
The NF-V6 Sharp A2 Volcano Hardened Steel Nozzle can be purchased from the following websites:
AliExpress
E3D
If you haven’t lived under a rock, you’ve probably heard about E3D. They made the really popular V6 hotend and they are the reason why most of the nozzles we get now have the “standard” V6 thread. Their latest popular product is the E3D Hemera extruder which is on my Ultimate 3D Printer Upgrades list.
E3D always focused on delivering high-quality printing hardware for 3D printers and this can be seen in the quality of their products.
Brass V6 Nozzle
The Brass V6 nozzle is the cheapest offering from E3D and it’s the one which comes with the V6 hotends. Machining is good and you should get good results with it when printing regular materials like PLA, PETG, TPU and ABS.
The E3D Brass V6 Nozzle can be purchased from the following websites:
E3D Online
Brass V6 – 0.15 mm Nozzle
I also got a 0.15 mm nozzle and the nozzle hole is really tiny. It’s the same material as the regular V6 and considering the size of the hole, it’s pretty impressive to see that E3D can machine something like this. Not sure if it can be successfully used for consistent prints but I will try it out and share the results.
The E3D Brass V6 0.15 mm Nozzle can be purchased from the following websites:
E3D Online
Hardened Steel V6 Nozzle
The hardened steel V6 nozzle from E3D maintains the same good machining. The nozzle coating is really dark and hard to photograph, but it’s one of the most durable nozzles in their line-up. The hardened steel nozzle is great for printing abrasive materials like carbon fiber infused filament or glow in the dark. Just remember to always do a temperature test in advance, because usually hardened nozzles need about 10C more due to their lesser thermal transfer.
The E3D Hardened Steel V6 Nozzle can be purchased from the following websites:
E3D Online
Nozzle X V6
The Nozzle X V6 is probably E3Ds flagship nozzle because it offers abrasion resistance and a coating to avoid material build up. This should make the nozzle easier to clean and printing sticky materials like PETG should be easier compared to a regular nozzle.
Machining is good and the coating has a similar color to the Vanadium nozzle from Slice Engineering.
The E3D Nozzle X V6 can be purchased from the following websites:
E3D Online
Stainless Steel V6 Nozzle
The stainless steel nozzle from E3D is a “bridge” between the regular brass nozzle and the hardened steel nozzle. I call it a bridge because it offers better abrasion resistance compared to brass, but it’s not as good as the hardened steel. The thermal performance is also not as good as brass, so I can’t say this is a nozzle I see myself using too much.
I’d rather print with a brass nozzle and replace it after it wears down, instead of using the stainless steel nozzle.
The E3D Stainless Steel V6 Nozzle can be purchased from the following websites:
E3D Online
Brass Volcano Nozzle
The brass volcano nozzle is the same as the regular brass V6 but made specifically for Volcano heatblocks which allow you to print faster. My particular nozzle is a 0.6 mm nozzle, so in combination with the volcano heat block can lower your print times significantly.
The E3D Brass Volcano Nozzle can be purchased from the following websites:
E3D Online
Copper Plated Volcano Nozzle
With the copper plated volcano nozzle, E3D tries to harness the best thermal performance offered by the copper and put it into a volcano form factor. The copper plated nozzle should be the best choice when printing at high speeds with high flow and it should allow the filament to be melted faster compared to a brass nozzle.
The machining is good, plating quality is great and I don’t have any complaints for it.
The E3D Copper Plated Volcano Nozzle can be purchased from the following websites:
E3D Online
Nozzle X Volcano
Just like it’s smaller sibling, the Nozzle X volcano has the same coating which repels plastic and makes it easier to clean. Unfortunately, my sample had a small “ding” in the tip. Considering that the small defect is not inside the extrusion hole, I don’t think it will have any impact in print quality. But if you consider the price, you would expect the nozzle to be flawless.
The E3D Nozzle X Volcano can be purchased from the following websites:
E3D Online
Hardened Steel Volcano Nozzle
With the hardened steel volcano, you get the same great abrasion resistance in a volcano form factor which should be great for printing abrasive materials at a high printing speed. Good machining quality, and overall a nice finish.
The E3D Hardened Steel Volcano Nozzle can be purchased from the following websites:
E3D Online
Phaetus
V6 Hardened Steel Nozzle
The hardened steel nozzle from Phaetus is the one to use if you plan to print abrasive materials. It’s important to use this nozzle only if you mainly use abrasive materials, because the thermal transfer is not as good as brass or copper plated nozzles. As you can see, the machining quality is great, and there’s nothing to complain about it.
The Phaetus V6 Hardened Steel Nozzle can be purchased from the following websites:
V6 Plated Copper Nozzle
The V6 Plated Nozzle from Phaetus is best suited for printing PETG and TPU which tends to stick to the nozzle. But it works with any type of material, increasing the thermal transfer between the block and the material. My sample had some tiny marks on the side of the tip, but I don’t think it impacts the print quality considering how small they are. The price is also similar to other plated copper nozzles out there.
The Phaetus V6 Plated Copper Nozzle can be purchased from the following websites:
V6 Brass Nozzle
This is probably the cheapest V6 Nozzle from Phaetus. For around 5$, it’s one of the best nozzles you can get if you want to keep the cost low. The machine quality is good and I can’t really complain about anything at this price point.
The Phaetus V6 Brass Nozzle can be purchased from the following websites:
Artillery
Stock Volcano Brass Nozzle
This badly machined nozzle which is included with all the Artillery printers made me want to do a comparison between all the nozzles. I always said that the nozzle should be the first upgrade to do for the Sidewinder X1 and Genius. The included nozzles are just plain bad and you can see that in the images below.
The hole is not cut well and you can’t expect accurate extrusion with something like that. The tip is also not smooth which can cause some uneven layers. Just replace it as soon as possible with a better nozzle and I guarantee you will get better prints.
The Stock Volcano Brass Nozzle can be purchased from the following websites:
AliExpress
No-Name
Generic Cheap V6 Brass Nozzle
This V6 brass nozzle was purchased for 20 cents just so you can see how bad some nozzles can be. Sure, you can’t expect any quality from such a cheap nozzles but this is a good example of a bad nozzle. If your nozzle looks like this, then it’s time for an upgrade.
The Generic Cheap V6 Brass Nozzle can be purchased from the following websites:
AliExpress
Generic Cheap V6 Stainless Steel Nozzle
This Stainless Steel nozzle has a really bad thermal transfer besides the bad machining. I needed to increase the temperature with a whopping +20C just to be able to print PLA. Even after I did this, the layers would not bond properly. Avoid this at all costs.
The Generic Cheap V6 Stainless Steel Nozzle can be purchased from the following websites:
AliExpress
Generic Cheap Sharp Brass Volcano Nozzle
This Volcano nozzle wins the “Worst Nozzle In This Test” trophy. I wasn’t even able to test it because the tip is clogged from machining chips. I’m also not sure if it’s made from real brass because it has a somewhat different color. Looks like it’s just painted to look like brass.
The Generic Cheap Sharp Brass Volcano Nozzle can be purchased from the following websites:
AliExpress
Slice Engineering
Slice Engineering got really popular since they released their Mosquito Hotend which is one of the best hotends available right now. They don’t have the cheapest products available, but you get what you pay for.
Every piece of hardware I got from there has ridiculously good machining. That’s why I can easily recommend them if you are looking for the best quality out there.
Vanadium™ Nozzle
The Vanadium Nozzle is an excellent high-temperature material nozzle. It’s made from Vanadium alloy for improved abrasion resistance. This nozzle can be a good choice if you already have a Mosquito Hotend and you plan to print at high temperatures or with abrasive filaments.
Slice Engineering trusts this nozzle so much that it offers a lifetime warranty for any abrasion damage making the purchase price a bit more forgiving.
It’s coated with a plastic repellent coating which works really well and even after a few hundred hours of use, mine looks great. It’s also made 100% in USA if that’s something you care about.
As you can see, machining is excellent. This is something Slice Engineering does really well with all their products so there’s no surprise here. For some reason, even tough is made from hardened steel, I didn’t need to increase my print temperature with this nozzle but maybe it has something to do with the Mosquito.
I would have loved to see a similar nozzle but in a Volcano format because it really is a great nozzle.
The Vanadium™ Nozzle can be purchased from the following websites:
SliceEngineering – Use 3DPRINTBEGINNER code for a small discount (affiliated code)
Ollson Ruby
Olsson Ruby V6 Brass Ruby Nozzle
Another example of a broken ruby nozzle.
I got an Olsson Ruby Nozzle and after only ~20-30 hours of printing it “died”. The ruby tip got cracked and now I have an expensive paperweight. Because the tip is not made from the same material, it has lower heat transfer. Can’t say if this is good or bad, but I now keep it in my nozzle box waiting to be used at some point.
Considering the huge premium, you pay for a ruby nozzle and how easily they can be damaged, I don’t really recommend buying one.
The Olsson Ruby V6 Brass Ruby Nozzle can be purchased from the following websites:
OlssonRuby
Amazon
BIQU
Stock V6 Nozzle
This is the nozzle I got with the BIQU B1 printer. It has the same V6 compatibility but with a much bigger brass head. I think this is made for storing more heat and somehow compensate for the bad aluminum block.
Anyway, it works well and the machining is better than expected. It has a small ding on the side of the tip but no issues encountered during printing.
The BIQU Stock V6 Nozzle can be purchased from the following websites:
AliExpress
Creality
Creality MK8 Nozzle
I always liked the Creality nozzles for some reason. I was able to print well will them and I wasn’t really surprised when I put one under the microscope.
The machining quality is close to the one you get from Trianglelab and Mellow so I don’t really see a reason change them for a similar brass nozzle.
Maybe only if you want to upgrade for a plated copper nozzle, but otherwise these should be fine. Anyway, if you replace them make sure you buy the same nozzle from Creality because I know there are other manufacturers which make worse nozzles and sell them with the same branding.
The Creality MK8 nozzle can be purchased from the following websites:
AliExpress
Mingda
Mingda D3 Pro Nozzle
This is the stock nozzle which comes with the Mingda D3 Pro and the quality is good. Not as good as other nozzles listed here, but overall it’s decently machined and it performed well during my time with the printer.
Raise 3D
Raise 3D E2 Brass Nozzle
This is the stock brass nozzle you are getting with the Raise E2 printer. It’s sharper than other nozzles, but it uses the same M6 thread as a regular V6. There’s also a small particularity in the point of contact of this nozzle to the heat break. There’s a small cut to better match the heat break and make sure the contact is perfect.
The overall quality seems fine, but nothing to write home about.
Raise 3D E2 Hardened Nozzle
The hardened nozzle from Raise 3D looks a bit better than the brass version, and overall, it’s much cleaner looking. I haven’t tested it yet, but I will update the article with impressions when I do.
Wrapping up
Hopefully, this article helped you see some of the differences in build quality between various nozzles. Now you should be able to make an informed decision if you want to replace your nozzle.
Check back soon because I plan to do constant updates to this article, when I get my hands on different nozzles. If you want to see a specific nozzle tested, leave me a message below and I will try to add it to the comparison.
If you are wondering what other upgrades you can do to your printer, make sure you read my Ultimate 3D Printer Upgrade Purchase Guide where I covered my favorite 3D printer upgrades.
While this article contains affiliate links, all opinions are my own. Please make your own decision before purchasing anything.
